Test Measurement Probe Cable Assembly for RF Switch Connector
Fully Compatible with Murata SWD MM8430-2610 SWF MM8130-2610 SWG MM8030-2610 series, Hirose MS-180 series, 100% Equivalent. Cross Reference - Murata MXHS83QE3000 MXHQ87WA3000 ; Hirose MS-180-040LP-H3 MS-180-088LP-H1
To meet the rigorous reliability demanded by smartphones and mobile IT devices, a RF switch is typically installed on the main PCB as a contact port for assurance testing. Driven by economy of scale and standardization, only a handful of de facto brands occupy 95%+ of the market share of the RF switch: Murata SWD/SWF series, Murata SWG series, Hirose MS-180 series. As this RF-antenna circuit test becomes a must for production and field service, the demand calls for a test probe device (usually in cable assembly form) that is reliable, durable and easy to use. Sunridge TP series offers a complete line of "Test Probe to SMA" cable to fulfill this requirement.

Product Spec

Product details

Complete test probe line for Murata SWD or SWF and, SWG, Hirose MS-180 series of RF switch.
Option in height and engagement force - to fit application and to accommodate test-bench setups.
1.35mm OD cable - RG178 performance grade, with routing flexibility.
TP-SMA adapter available - to convert TP contact tip to SMA Jack, which can be connected to a network analyzer - for calibration measurement or zero-in of the test-probe cable assembly.
